SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck

SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck

  • SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck
  • SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck
  • SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck
SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck
Szczegóły Produktu:
Place of Origin: China
Nazwa handlowa: SINOTRUK
Orzecznictwo: ISO/3C/BV/IFA/SGS
Model Number: 4.9m Length cargo body
Zapłata:
Minimum Order Quantity: 1 Unit
Cena: negotiation
Packaging Details: Nude or Waxing in Roro or bulk ship
Delivery Time: 25 working days after received your advance payment
Payment Terms: L/C, T/T, Western Union
Supply Ability: 2,000units per month
Kontakt
Szczegółowy opis produktu
Min. Temperatura: -18℃ Model: Nadwozie o długości 4,9 m
Nazwa produktu: chłodnie panele CKD Wymiar zewnętrzny: 4900*2100*2100mm
Wymiar wewnętrzny: 4735*1935*1900mm Tom: 17CBM
Ładowność: 6-12 ton Podłoga aluminiowa: 10,6 zł
boczne drzwi: JEDEN Technologia: Niemiecki
High Light:

ciężarówka chłodnia

,

ciężarówka chłodnia

,

ciężarówka chłodnia SINOTRUK

SINOTRUK Insulated CKD Panels, for making refrigerated truck cargo body



Description:



SINOTRUK Insulated CKD Panels, for making refrigerated truck cargo body

Refrigeration unit for refrigerated trucks, refrigerated trucks Everfount container provides the "cold" important equipment, usually installed in front of the top of the container, the air conditioning is like appearance, but the cooling capacity is stronger than the same volume of air conditioning.



The refrigeration unit is generally divided into two types, independent units and non independent units, the unit is completely independent difference through a unit to maintain the power supply in addition, non independent refrigeration unit is completely through the vehicle engine power to drive the turbine.



Generally according to the volume of refrigerated compartment and transport of goods to the requirements of the temperature, to choose different power refrigeration units.



Refrigerated truck refrigeration unit for temperature control, and the carriage body is used to maintain temperature. If the refrigeration unit is the energy provider, then the body is energy storage. In three parts of refrigerated trucks, the refrigeration unit and the insulated body is the most important, in addition to the chassis can be used as small insulation, cold storage.





Specification:



SINOTRUK Insulated CKD Panels, for making refrigerated truck cargo body

Outside Dimension

4900*2100*2100mm

Inside Dimension

4735*1935*1900mm

Volume

17.00CBM

ANTI-PRESSURE

>180MPa

Van Heat Transfer Coefficient

≤0.3W/M2﹒K

ANTI-CURVE

>220MPa

CUT STRENGTH

>24.6MPa

Side door

1

Aluminum floor

10.6 ㎡

Main Components

body assembly

Material

Freon-free polyurethane, and GRP material

Floor or roog



105mm




Applications:





Refrigerated Truck can widespread use in transportation of all kind of frozen food, vaccinum, vegetables and fruit.



Competitive Advantage:



1) Our company's production of circular easy brand refrigerator car introduced Italy,

Germany, the United States overall polyester foam technology, and high strength fiber

plastic and other material  manufacturing technology and equipment

2) so that our company refrigeration, heat preservation technology level basic reached

world advanced  water level.
3) Refrigeration, heat preservation car body with light, high strength, good heat

insulation performance,  high temperature stability, no pollution, oxidation, easy

maintenance, but also has low noise, low energy consumption, low failure rate, food

preservation effect is good and so on a series of advantages
4) A lot of technical indicators and the world's advanced level is close to the fully

closed polyurethane  plate bonded glass steel structure, this product is light weight,

low heat leakage.

5)with all kinds of truck model, which can fulfill your requirement
6) the key parts adopt the world's top technology products
7) based on strong technical support and top level technology make the trucks with high

quality and more reliable
8) competitive price, cost-effective

9) quick and efficient spare parts supply bring you more convenient

10) fast delivery time, we can arange production according to your needs exactly and quickly

11) professional import and export dealing precedure, make customs clearance more high efficiency



SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck 0SINOTRUK Insulated Refrigerated Truck CKD Panels -18℃ For Refrigerator Truck 1
